Family Package Ice Cream Filler
It is designed for dispenser ice cream into large size plastic or paper containers of various shapes, such as: square, round, oval and other shapes (500ml~2000ml). Ice cream filling can be with two or three colors and other various patterns.
The machine is controlled with PLC and operated by touch screen, which is stable and reliable.
Technical Parameter | ||
Model | DB-20 | |
Maximum Capacity | 600kg/h (depend on the freezer speed) | |
Filling Quantity | 600~1500ml (according to the container size) | |
Voltage | 3ph, 380V, 50Hz | |
Air Pressure | ≤0.6Mpa | |
Size | 1300*600*1600mm | |
Weight | 300kg | |
Standard Machine Configurations | ||
Main machine body and frame | The main machine frame is by stainless steel 304 and outside covered with stainless steel 304 sheet | |
Accessories | Equip with Jam Pump station and distributor | |
Cylinder | Airtac Brand Cylinder | |
Electrical elements | Chinese brand (Chint) | |
PLC and Touch screen | Chinese brand (Xinjie) | |
